Basic Info
Shape: T - Profile
Temper: T3-T8
Alloy: Alloy
Alloying Ingredient: 6063
Surface Treatment: Anodized
MOQ: 200KG
Type: Decoration Aluminium Profile
Grade: 6000 Series
Certification: ISO9001
Color: matt bronze or customized
Thickness: 0.8mm-5mm
Payment Term: T/T,L/C at Sight
Transport Package: poly bag + carton or customized
Origin: China
Product Description
T shaped Aluminum tile trim for carpet and tile
Xingtaomei Aluminum Co.,Ltd has more than 20 years in designing ,production ,and exporting of aluminum alloy flat bar,tube,round and square pipes, tile trims and all profiles for decorations and industrial use, including cabinet profiles, wardrobe profiles, furniture profiles, LED profile, aluminum floor/carpet trim, tile trim, wall edging, stair nosing, high partition profiles, screen profiles, air purifier profiles, diffuser profile, tent profiles, etc.
1. Material of T shape Aluminum tile trim
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
| 6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
| 6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2. Color: Glossy and semi-glossy, matt, available in Silver, champagne, bronze,gold, black, etc.
3. Mechanical properties of Aluminum tile trim under room temperature
| Alloy | Temper | Tensile strength test | Hardness test | |||||
| Thickness(mm) | Tensile strength RM(N/mm2) | Non-proportional stretching stress Rp0.2(N/mm2) | Stretching rate A50mm(%) | Pattern thickness(m) | HV | HW | ||
| 6061 | T4 | All | >=180 | >=110 | >=16 | - | - | - |
| T6 | All | >=265 | >=245 | >=8 | - | - | - | |
| 6063 | T5 | All | >=160 | >=110 | >=8 | >=0.8 | >=58 | >=8 |
| T6 | All | >=205 | >=180 | >=8 | - | - | - | |
6. Application of Aluminum tile trim
Suitable for uses in homes, offices, studio, hospitals, theaters, classrooms, concert halls, libraries, recreation hall, theater lounge, shops, hotels, restaurants and inside the stadium.
Q：If the products have quality problems, how will you handle it?
A：Please send the pictures to our sales representatives. If the problem is confirmed, we will arrange exchange of products.
Q：How long will it take for delivery after we place the order?
A：For mould opening, it takes around 7-10 days. For mass production, it takes around 20-30 days.
Q: How long will it take to open a new mould/die?
A: Generally it will take 7-10 days to open an extrusion mould/die and 10-15 days to open a punching mould/die. Bigger moulds/dies will take longer time.
Q: Will you provide samples?
A: Yes. We can provide samples free of charge.
Q：Can you provide accessories for installing tile trims, floor trims, etc.?
A：Yes, we can provide accessories like corner pieces/end cap, screws, etc. Please consult our sales representatives. You might need to provide samples for this service.
